Trek Fuel EX 5 Gen 7 – Lithium Grey/Trek Black Splatter

Name: Trek Fuel EX 5 Gen 7 - Lithium Grey/Trek Black Splatter
Brand: Trek
SKU: 56310-ch-bk
Price: 2399.00 EUR
Availability: InStock

2399,00 €

Incl. VAT 25,5 %

Instalments from. 72,63 €/month With Zaver

Sizes

Clear

Quick delivery straight to your door for just 34,90 €

Fast deliveryStraight to your door

Manufacturer's warrantyAuthorised dealer

First service −50%For bikes bought from us: bikes €60, e-bikes €80

14-day return policyIn accordance with consumer protection law

Description

Monipuolinen alumiinirunko, jossa säädettävä jousitus ja geometria räätälöityyn polkusuoritukseen.

Aluminium trail bike with 150mm fork, 12-speed Shimano Deore, dropper post, and adjustable suspension, designed for versatile trail use.

This model features an Alpha NEXT Platinum aluminium frame with adjustable geometry and leverage rate to customize suspension performance. Suspension parts include 150 mm travel fork and a 205x60 mm rear shock. The 12-speed Shimano Deore drivetrain ensures reliable shifting and broad range with 10-51 cassette. Hydraulic disc brakes with 180 mm rotors provide effective stopping power. Bontrager Comp alloy bars and stem, with Bontrager Verse Short saddle complement the build. Tubeless-ready wheels and tires reduce punctures and improve rolling resistance, and a TranzX JD-YSI34 dropper post offers 150-170 mm travel depending on frame size, routed internally for a clean setup.

What you get

Key features

Monipuolinen alumiininen trail-pyörä, joka sopii erityyppisiin maastoihin
Varustettu RockShox Recon Silver -haarukalla, jossa 150 mm:n jousto
X-Fusion Pro 2 -takaiskari säädettävillä asetuksilla
Tubeless-valmiit Bontrager Gunnison Elite XR -ulkorenkaat
12-vaihteinen Shimano Deore -voimansiirto tarjoaa laajan vaihdealueen
TranzX dropper post with internal cable routing
Boost-standardin navat lisäävät kiekon jäykkyyttä ja kestävyyttä
Säädettävä rungon geometria ja vipuvarsisuhde jousituksen säätöä varten
Integroitu rungon säilytystila ja lisävarustekiinnikkeet
Hydrauliset levyjarrut 180 mm:n jarrulevyillä tarjoavat luotettavan pysäytysvoiman

Specifications

Technical Information

Specifications

Brakes	Shimano MT200
Drivetrain	Shimano Deore, 12-speed
Fork	RockShox Recon Silver, 150 mm
Frame	Alpha NEXT Platinum Aluminium, 145 mm
Handlebar	Bontrager Comp, alloy
Rear shock	X-Fusion Pro 2
Tyres	Bontrager Gunnison Elite XR
Weight	M - 17.02 kg / 37.53 lbs (TLR-tiivisteaineella, ei sisärenkaita)
Wheels	Bontrager Line TLR 30
specForktravelMax	170 mm
Headset part (see also: Bearing)	1-1/8'' threadless, sealed cartridge bearings
Seatpost part	Bontrager Line Dropper remote
Valve	Bontrager TLR valve, 50mm

Drivetrain

Max. chainring size	Maks: 34T (soikea – 32T) Min: 30T (soikea – 32T)
Chain	Shimano Deore M6100, 12-speed
Crank	Shimano MT512, 30T ring, 55 mm chain line, 170 mm length
Rear derailleur	Shimano Deore M6100, long cage
Cassette	Shimano Deore M6100, 10-51, 12-speed
Bottom bracket	Shimano BB-MT501 BSA
Shifter	Shimano Deore M6100, 12-speed

Components

Rotor size	Max brake rotor sizes - Frame: 203 mm, min 180 mm, Fork: see fork manufacturer
Head set	FSA Orbit, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom, 1.5 crown
Stem	Bontrager Comp, 31.8 mm, 7-degree, 35 mm length
Saddle	Bontrager Verse Short, stainless steel rails
Handlebar	Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width
Brake rotor	Shimano RT10, CenterLock, 180 mm
Brake	Shimano hydraulic disc, MT201 lever, MT200 calliper
Grips	Trek Line Comp, nylon lock-on
Seatpost	Array

Wheels

Max tyre size	Runko: 29x2.50", Haarukka: Katso valmistajalta
Hub front	Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Skewer rear	Bontrager Switch thru axle, removable lever
Hub rear	Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Tyre	Array
Tyre part	Bontrager TLR sealant, 180 ml/6 oz
Rim	Bontrager Line TLR 30, Tubeless-Ready, 28-hole, Presta valve
Rim strip	Bontrager TLR

Weight

Weight	M - 17.02 kg / 37.53 lbs (TLR-tiivisteaineella, ei sisärenkaita)
Weight limit	This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).

Frameset

Shock	X-Fusion Pro 2, 2-asentoinen vaimennin, 205 mm x 60mm
Fork	Rockshox Recon Silver RL, Solo Air -jousi, Motion Control -vaimennin, lukitus, kartiomainen ohjainputki, 42 mm:n offset, Boost110, 15 mm Maxle Stealth, 150 mm:n jousto
Frame	Alpha NEXT Platinum aluminium, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145 mm-160 mm

Dimensions

Geometry

Measurements in centimetres unless otherwise stated. We recommend a test ride and fitting in store.

Fitting

Size Chart

Size	Rider Height	Inseam
S	155-165	74-78
M	165-177	79-83
L	177-188	84-89
XL	188-195	89-91

We always recommend trying the bike in store — book a free fitting appointment.
